Steel Wagon Unloading System Rotary Wagon Tippler Bulk Materials Handling

Name: Steel Wagon Unloading System Rotary Wagon Tippler Bulk Materials Handling
Brand: SSI-hdcz
Price: 1 USD

China Steel Wagon Unloading System Rotary Wagon Tippler Bulk Materials Handling wholesale

Brand Name : SSI-hdcz

Model Number : SSI-2

Certification : manufacture certificate

Place of Origin : china

MOQ : 1

Price : US $1,500,000-5,000,000/ Set

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 20 sets / year

Delivery Time : 6 months after receipt of advance payment

Packaging Details : Wooden case or bare

material : high quality steel

product : wagon unloading system

painting : jotun

model : SSI-2

character : durable

performance : high efficiency

benefit : low cost

advantage : cost effective

Contact Now

Wagon unloading system rotary wagon trippler bulk materials handling solution

Wagon unloading System is designed for bulk material unloading system, which is used for the dumping of bulk materials loaded by trains. The wagon unloading system has high unloading efficiency and less damage to rail cars. It can improve the working environment of personnel on duty and facilitate the automatic control of machinery. With the continuous development of the national economy, the consumption of bulk materials transported by train such as coal, coke and ore required for the construction of thermal power plants, smelters, cement plants, ports and mines has increased significantly. The wagon unloading system has been widely used in large modern enterprises.
Based on requirements, various wagon unloading solutions can be applied including rotary tipplers, C-type rotary wagon tipplers and side-unloading wagon and our systems are able to unload a rail car even when there are wagons of differing sizes.

Selection parameters of rotary wagon trippler
Number of vehicles overturning at the same time	Type		Tipping capacity	Applicable models	Model size(mm)			Tipping weight (T)		Rotation angle (°)		Slewing speed	Starting and braking time	Rotation time
Number of vehicles overturning at the same time			(knots / hour)		long	wide	high	rated	max	normal	max	r/min	s	s
1	C	Turn back	20-24	C50～C60	11938～14038	3140～3243	2790～3594	100	110	160	175	1	8	65-75
2	O	penetration	58-74	C60	It can be adjusted according to the actual model			2x84	2x110	160	170	2.8	8	35-45
2	C	Turn back	32-36	C60				220	240	165	175	1.2	8	50-70
3	O	penetration	90	C80～C100				300	372	165	180	1.885	6	40-60
3	C	Turn back	42	C61～C96				300	372	175	175	1.09	8	50-75
4	O	penetration	112	C80				400	ellipsis	165	ellipsis	1.885	3	35-45

Photos of our factory
